MITH
Carbon fibre monocoque with 160mm of rear travel. Virtual pivot suspension system. Integrated display, battery, chain guide and seat tube clamp. Motor protector. EnduroMAX Bearings. Internal cable routing. Boost thru axle 12x148. Post Mount brake system. Max tire width: 2.6”. Recommended SAG: 30-35%.
MOTOR
DJI Avinox
2,52 Kg drive unit with 70Nm (Eco), 105Nm (Auto, Trail, Turbo) and 120Nm (Boost). Offers 250W (rated), 850W (peak) and 1000W (max.) of power.
DISPLAY
DJI Avinox 2-inch OLED
2-inch OLED smart multi-function touchscreen with 800 nits and 326 ppi.
CONTROLLER
DJI dual Wireless Controllers
Wireless Controllers with Bluetooth Connectivity
BATTERY
DJI Avinox 800Wh
Integrated 3.74kg battery, delivered with a fast charger, 0 to 100% in 2h 25min.
HEADSET
ACROS Block-Lock
135º w/ CANE CREEK spacers
SUSPENSIONS
FORK
Fox 38 Factory
170mm travel. Kashima coating. Grip X2 damper. Adjustments: HSC, LSC, HSR, LSR. 44mm offset.
SHOCK
Fox Float X2 Factory
230x65mm. Kashima coating. 2-pos lever. VVC Rebound. Adjustments: HSC, LSC, HSR, LSR.
TRANSMISSION
DERAILLEUR
SRAM X0 Eagle AXS T-Type
12 speed. AXS Wireless. T-type.
CONTROLLER
SRAM AXS
AXS Pod Controller Rocker Paddle
CHAINRING
UNNO 36t
CASSETTE
SRAM X0 T-Type
XS- 1295. 12 speed. 10-52t
CHAIN
SRAM X0 T-Type
120 links. Flat top. 12 speed
CRANKSET
E13 Helix Core e*spec
155mm
WHEELSET
WHEELS
NEWMEN Phase 30 Carbon
Mullet 29" Front and 27.5" Rear.
FRONT TYRE
SCHWALBE Magic Mary
Ultra Soft, Gravity Pro, TLR, 29” x 2.5”
REAR TYRE
SCHWALBE Magic Mary
Soft Evo, Gravity Pro, TLR, 27.5” x 2.5”
BRAKESET
BRAKES
Formula Cura 4
4x18mm pistons on Caliper. SRAM Mixmaster. Sintered Pads. Axial Master Cylinder. Forged Aluminium. 850mm front hose and 2000mm rear hose.
ROTORS
Formula
203mm front rotor, 200mm rear rotor with integrated speed sensor slots.
COCKPIT AND SEAT
COCKPIT
OneUP
ONEUP V2 Carbon handlebar, 35mm diameter, 800mm length, 35mm rise & ONEUP 42mm stem
DROPPER
OneUp V3
Mechanical. Travel: 180mm, 31.6mm - 22.2mm
SADDLE
FIZIK Terra Aidon X5
145mm
